Overview of TAPCO's Intelligent Warning Systems

From products shots to real life on location examples.

Curve Warning & Guidance Systems (CWGS™)

BlinkerBeam® wireless communication, BlinkSync™ synchronization & chevrons function dynamically to warn and guide motorists through a dangerous curve once activated; by directing the chevrons to flash sequentially - delivering the "pull-through" effect. The system flash pattern and timing are easily programmed wirelessly from the Windows-based software using a PC or laptop, enabling the user to tailor the flash sequence to match the speed of traffic and the size of the curve.


The day and night curve warning & guidance solution

Features & Advantages

  • Reduce speed-related crashes
  • Reduce head-on and cross-median crashes
  • Prevent/mitigate roadway departure crashes
  • Green, solar power - zero electrical costs
  • Delineates curves
  • Install anywhere

Further enhance with an advanced curve warning sign

A flashing LED Curve Warning BlinkerSign® warns drivers that they are approaching a curve early given them more time to react at critical areas like cliff drop offs.

Sequential Dynamic Curve Warning System, Empire CO

TAPCO's Dynamic Curve Warning Systems, or DCWS. These DCWS feature TAPCO's flashing LED BlinkerSign, which are solar-powered traffic signs enhanced with brilliant LEDs. The BlinkerSign provide advanced warning of and guidance through the curve, and are ITS-compatible.

Watch video »

Standard Specifications
Sign MUTCD # W1-8R or W1-8L
Sign Substrate .080 Highway Grade Aluminum
Reflective Sheeting 3M™ DG3™ - with anti-graffiti Overlay
MUTCD Compliance MUTCD Section 2A.07 Compliant
Battery Nickel Metal Hydride (NiMH)- 14,000mAh
Battery Lifespan Up to 5 years
Autonomy (Functionality without Charge) Up to 30 days in 24/7 operation
Flash Pattern MUTCD Compliant
LED Type High Power Luxeon - 1 watt
LED Life Expectancy Over 100,000 Hours
Warranty 2 Year

DISCLAIMER: These specifications are for the blinker / beacon system only and doesn't include the specifications for the add-on smart activations. Specifications are subject to change without notice. For additional specifications and details, please contact us!

BlinkLink™ Web-based Traffic Device Monitor & Control Software System

Monitor BlinkerSign® and other ITS device status from any web-enabled computer. Comprehensive management of all device settings, schedules and messages. Real-time information allows you to respond immediately to changing situations.

Learn More »

IWS-blinklink.pdf | file size: 1.9mb


Vehicle Speed Sensor

A low power draw Digital Signal Processing (DSP) based K-band radar for ITS sign activation and traffic calming. It is the premier product in its class available in the world.

  • World's smallest and lowest power usage OEM K-Band Doppler radar, up to 25X lower than some other industry offerings
  • Firmware "boot loader" allows for field upgrading of firmware
  • Settings configurable via RS232 serial port
  • 300+ feet typical pickup range for a compact vehicle
  • FCC pre-approved
  • Simple rotary switch or thumbwheel input available to set threshold
  • Two LED Lamp outputs to drive .8W LED lamps with dimming

24/7 Activation

24/7 is the always on setting.

The purpose of the High Risk Rural Roads Program (HSIP) is to achieve a significant reduction in traffic fatalities and serious injuries on all public roads.

http://safety.fhwa.dot.gov/local_rural/training/fhwasa10012/

Discuss Options With Us

Call us at 1-800-236-0112

Other Activation Methods Available

Do you have a unique problem requiring a custom activated BlinkerSign® system? For years TAPCO has been providing custom stand-alone solar solutions. These electrical grid independent systems provide reliable warning when needed most-in harsh environments, dangerous areas and remote locations.

  • Climate activation (fog, snow, ice, wind, etc.)
  • Water sensor (flood detection)
  • In-ground inductive loop
  • Overheight detection
  • Temperature sensor
